Frequency 50/60 Hz
Rated Input power 8 KVA
Range Working Voltage 26 V
No-load Voltage 70 V
Range Of Output Current 20~160 A
Ratd Input Current 32 A
Diameter Of Electrode 1.6~4.0 mm
Rated Duty Cycle 60%
Power Factor ≥0.99
Efficiency ≥ 85 %
Insulation Type H
Protection Type IP21S
Weight 4.2 KG
